Rectron
Huawei Power M - 10kW
Huawei Power M - 10kW
Regular price
R 110,999.00 ZAR
Regular price
R 124,999.00 ZAR
Sale price
R 110,999.00 ZAR
Unit price
/
per
Couldn't load pickup availability
PRICE EXCLUDES INSTALLATION AND DELIVERY
- HUAWEI 15kW Intelligent Power Mate iSitePower-M Energy Storage Module
- Model IPM-MAB05B1
- Includes Only: HUAWEI 5kW Intelligent Power Mate iSitePower-M Energy Storage Module (IPM-MAB05B1)
- For Use With HUAWEI 5kW Intelligent Power Mate iSitePower-M (Purchased Separately)
- Used to Increase Huawei IPM-5K-5Kwh capacity by 5kW per Module (up to 15kW)
- Recommended Packages:
- 5kW System (Small Shop): Aircons, Cashiers, Fans, Microwave Ovens.
- 10kW System (House): Aircons, TVs, Electric Fans, Refrigerators.
- 15kW System (Office): Aircons, Computers, Printers, Projectors.
- Weight: 50Kg
- Refer To Brochure For Detailed Product Specifications.
- 10 Year Limited Product Warranty or 6000 Cycles.
- Ultra-fast: 2-hour fast charge 100%
- Ultra-quiet: Fanless design, operating noise less than 29 dB Energy switchover without perception<10ms Smart priority management (Solar /battery /grid /DG) Smart mobile
- APP management: monitor device running status in real-time, help EPC & client efficiently manage the device. D.G. scheduling is supported, D.G. does not need to be started manually.
- Built-in energy optimizer, supporting mixed use of old and new lithium batteries
- Indoor scenario, floor-mounted
- Off-grid and unreliable grid areas, civil and commercial backup power
- AC mode – Single-phase/dual-wire: 85 – 290 Vac
- Input Power – Single-phase/dual-wire, 42A
- Input voltage – 58-150 V DC
- Input power – 8kW max
- Output voltage – Single-phase 200–230 Vac
- Battery capacity – 4.8kWh per battery
- Charging Power – 4.8kW max.
- Maximum parallel capacity – A maximum of three battery modules can be connected in parallel, 14.4 kWh.
